LPOSRV2-M24

PDF Download

Description

A pilot-operated pressure limitation and feed valve

SYMBOL

Contact Us

Up all

Pack up all

  • Technical Feature


  • Technical Data

    Operating Pressure
    420Bar
    Flow
    See PRESSURE DROP VS.FLOW graph.
    Cavity
    Rexroth-FB
    Max.Operating Pressure
    42Mpa
    Torque
    80-90Nm

  • File Download

    PDF File
    LPOSRV2-M24

  • ACCESSORIES
